Driving Simulation Platform



1. High precision vehicle dynamics simulation

-Support 6-degree-of-freedom motion platform to simulate real driving experience

-Integrate physical engines such as tire models, suspension systems, and power transmission



2. Multi sensor fusion simulation

-Support simulation of sensors such as LiDAR/camera/millimeter wave radar

-Implement closed-loop testing of perception algorithms in virtual environments



3. V2X communication simulation

-Support scenarios such as Vehicle to Road Collaboration (V2I) and Workshop to Vehicle Communication (V2V)

-Real time data exchange under simulated 5G/DSRC communication protocol



4. Construction of digital twin scenarios

-Support the import of real road data (high-precision maps/satellite images)

-Can generate custom traffic flow, obstacles, and emergencies



5. Hardware in the Loop (HIL) testing

-Compatible with mainstream real-time simulation platforms such as dSPACE/NI

-Support the integration of hardware devices such as ECU/domain controllers



6. Data collection and analysis

-Real time recording of driving behavior, sensor data, and algorithm output

-Provide visual analysis reports and performance evaluations





1. Hardware configuration	Sports platform: Adopting a 6-degree-of-freedom Stewart platform (pitch, roll, lift, etc.), supporting servo electric cylinder drive (response time ≤ 10ms), with a maximum load of ≥ 200kg; Some high-end models support 9-degree-of-freedom dynamic simulation (such as bumpy road surfaces and sideslip feedback). Display system: Standard 3-channel 42 inch LCD display screen, resolution 3840 × 2160, horizontal viewing angle ≥ 150 °; Optional VR headset or 180 ° surround screen projection, supporting 4K laser stereoscopic imaging. Input device: Real car level steering wheel (with force feedback), pedals, automatic transmission, compatible with DMS (driver monitoring system) and physiological monitoring module (heart rate, respiratory rate).
2. Dynamic performance	Simulation accuracy: The vehicle dynamics model supports real-time body simulation (error ≤ 3%) and can customize vehicle parameters (wheelbase, tire friction coefficient); Dynamic scene refresh rate ≥ 60Hz, action delay ≤ 20ms. Physiological parameter detection: Heart rate detection range is 30-200 beats per minute (error ≤ 3 beats), body temperature detection range is 30-42 ℃ (error ≤ 0.2 ℃); Support eye tracking (sampling rate 60Hz) and synchronized acquisition of EEG signals.
3. Software functions	Scene simulation: Built in scene templates for urban roads, expressways, extreme weather (rainstorm, ice and snow), and support user-defined road networks and traffic flows; Can be connected to V2X vehicle road collaboration system to simulate autonomous driving interaction. Data analysis: Real time recording of driving behavior data (steering wheel angle, throttle opening) and vehicle status (speed, acceleration), supporting CSV/Excel export.





Application:

✅1. Automotive R&D testing

-Autonomous driving algorithm validation (L2-L4 levels)



✅2. Driver training

-Driving School Subject 2/Subject 3 Virtual Training

-Special vehicle (forklift/mining vehicle) operation training



✅3. Military training

-Tactical driving simulation (off-road/riot scenes)

-Multi vehicle collaborative combat simulation



✅4. Research and teaching

-Practice of autonomous driving courses in universities

-Research on Traffic Engineering Simulation



Photos of Driving simulation platform



Packing: by container or as customers's required.

Delivery: deliver to major ports in your country.
